    SUPERMICRO MB LGA4677, C741, 8x DDR5 ECC, 4x NVMe, 10xSATA3, 2x M.2, 5x PCIe5.0, 2x 10Gb LAN,IPMI, MBD-X13SEI-TF-B

    Kód: ALIASBSRMBDX13SEITFB
    Neohodnoceno
    Značka: SUPERMICRO
    SUPERMICRO MB LGA4677, C741, 8x DDR5 ECC, 4x NVMe, 10xSATA3, 2x M.2, 5x PCIe5.0, 2x 10Gb LAN,IPMI, MBD-X13SEI-TF-B
    19 309 Kč 15 958 Kč bez DPH
    Skladem online (1 ks)
    Můžeme doručit do:
    27.12.2024
    Možnosti doručení

    Detailní informace

    Ověřený obchod
    Ověřený obchod
    Více než 23 let na trhu s IT
    SKLAD
    Sklad
    20 000 produktů připraveno skladem
    Výdejní místa KUPSIONLINE.CZ
    Široká síť výdejních míst
    Více než 7 000 výdejních míst v ČR
    Doprava zdarma
    Doprava zdarma
    Při nákupu nad 10tis. Kč doprava zdarma

    Detailní popis produktu

    Key Features




    1. 4th Gen Intel® Xeon® Scalable processors, Single Socket LGA-4677 (Socket E), CPU TDP supports up to 350W TDP

    2. Intel C741® Chipset

    3. Up to 2TB 3DS ECC RDIMM, DDR5-4800MT/s (1DPC) in 8 DIMM slots

    4. 2 MCIO (PCIe5.0 x8) connectors for 4 NVMe SSDs

    5. 3 PCIe 5.0 x8,

      2 PCIe 5.0 x16,

      M.2 Interface: 2 PCIe 5.0 x4

      M.2 Form Factor: 2280, 22110

      M.2 Key: M-Key

    6. Dual LAN with 10GbE with Intel® X550

    7. 4 USB 3.2 Gen1 (2 rear, 1 Type-A, 1 via header), 2 USB 2.0 (2 rear)

    8. Intel® C741 controller for 10 SATA3 (6 Gbps) ports























    Product SKUs
    MBD-X13SEI-TF
















    Physical Stats
    Form Factor

    • ATX
    Dimension

    • 12.3" x 10.3" (31.24cm x 26.16cm)
















    Processor
    CPU

    • 4th Gen Intel® Xeon® Scalable processors

    • Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP
    Core

    • Up to 60 cores




























    System Memory
    Memory Capacity

    • 8 DIMM slots

    • Up to 2TB 3DS ECC RDIMM, DDR5-4800MHz
    Memory Type

    • 4800/4400/4000MHz ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 4800MT/s (1DPC)
    DIMM Sizes

    • 16GB, 32GB, 64GB, 128GB, 256GB

    • RDIMM: 16GB, 32GB, 64GB, 128GB, 256GB
    Memory Voltage

    • 1.1V
    Error Detection

    • Corrects single-bit errors




























    On-Board Devices
    Chipset

    • Intel® C741
    SATA

    • Intel® C741 controller for 10 SATA3 (6 Gbps) ports
    IPMI

    • ASPEED AST2600 BMC
    Graphics

    • 1 Aspeed AST2600 BMC port(s)
    Network Controllers

    • Dual LAN with 10GBase-T with Intel® X550




































    Input / Output
    SATA

    • 10 SATA3 (6Gbps) port(s)
    LAN

    • 2 RJ45 10 Gigabit Ethernet LAN ports

    • 1 RJ45 Dedicated IPMI LAN port
    USB

    • 2 USB 2 port(s) (2 rear)

    • 4 USB 3.2 Gen1 port(s) (2 rear; 1 type A; 1 via header)
    Video Output

    • 1 VGA D-Sub Connector port(s)
    Serial Port

    • 1 COM Port(s) (1 header)
    DOM

    • 2 SATA DOM (Disk on Module) power connector support
    TPM

    • 1 TPM Header






























    Expansion Slots
    PCIe

    • 2 PCIe 5.0 x16,

    • 3 PCIe 5.0 x8,

    • 2 PCIe 5.0 x8 PCIe5.0 MCIO connector
    M.2

    • M.2 Interface: 2 PCIe 5.0 x4

    • Form Factor: 2280/22110

    • Key: M-Key
















    System BIOS
    BIOS Type

    • AMI UEFI
    BIOS Features

    • ACPI 6.4

    • SMBIOS 3.5 or later

    • UEFI 2.8












    Management
    Software

    • SuperDoctor® 5, SPM, SUM, SSM, IPMICFG, IPMIView for Linux/Windows, SMCIPMITool, Trusted Platform Module (TPM), Chasis Intrusion Detection




























    PC Health Monitoring
    Voltage

    • VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset Voltage, Chassis intrusion header, 6 -fan status, +5V standby, +5V, +3.3V, +12V, Memory Voltages
    LED

    • UID/Remote UID

    • CPU / System Overheat LED
    Temperature

    • Monitoring for CPU and chassis environment

    • CPU thermal trip support

    • Thermal Monitor 2 (TM2) support

    • PECI
    FAN

    • 7x 4-pin fan headers (up to 7 fans)

    • Fan speed control

    • Overheat LED indication

    • 7 fans with tachometer status monitoring
    Other Features

    • WOL, UID, Node Manager Support, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ACPI power management












    EAN:

    Doplňkové parametry

    Kategorie: Socket 4677
    Záruka: 3 roky
    Hmotnost: 1.3 kg
    Kód výrobce: MBD-X13SEI-TF-B
