    Domů / Počítače, notebooky / Počítače / Nové počítače / Servery / ASUS 1U server 2x SP5, 24x DDR5 4800 12x 2.5 NVMe/SATA, 2x 2600Wt, 4x 1Gb LAN, IPMI, 90SF02D1-M001A0

    ASUS 1U server 2x SP5, 24x DDR5 4800 12x 2.5 NVMe/SATA, 2x 2600Wt, 4x 1Gb LAN, IPMI, 90SF02D1-M001A0

    Kód: ALIASBRS700AE12RS12U12N1GOCP2600
    Neohodnoceno
    Značka: Asus
    ASUS 1U server 2x SP5, 24x DDR5 4800 12x 2.5 NVMe/SATA, 2x 2600Wt, 4x 1Gb LAN, IPMI, 90SF02D1-M001A0
    123 619 Kč 102 164 Kč bez DPH
    Vyprodáno
    Možnosti doručení
    Položka byla vyprodána…

    Detailní informace

    Ověřený obchod
    Ověřený obchod
    Více než 23 let na trhu s IT
    SKLAD
    Sklad
    20 000 produktů připraveno skladem
    Výdejní místa KUPSIONLINE.CZ
    Široká síť výdejních míst
    Více než 7 000 výdejních míst v ČR
    Doprava zdarma
    Doprava zdarma
    Při nákupu nad 10tis. Kč doprava zdarma

    Detailní popis produktu






























































    CPU

    Platform    		 CPU

    Scoket    		 CPU # U Max

    CPU TDP    		 Chipset Memory

    Type    		 Memory

    #    		 Storage

    #    		 Storage

    Bay    		 Storage

    Type    		 NVMe grade

    (option)    		 Storage

    Hotswap    		 SAS

    Controller    		 M.2 Other

    Storage    		 ODD O/B NIC GPU

    Sport    		 PCIe

    #    		 PCIe slots OCP PSU

    #    		 Railkit PSU

    Type    		 Heatsink

    Type    		 Depth

    (mm)
    EPYC

    Genoa    		 LGA6096 2 1U 400W SOC DDR5 4800 24 12 2.5" SATA/SAS/12xNVMe - Y Option 2 0 0   Intel-i350 Based

    1Gb x 4     		 - 2 1 x PCIe Gen4 x16, FHFL (CPU1)

    1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2)    		 3.0X1 1+1 1000mm

    Friction    		 2600W 80+ Titanium 1U EVAC HS 842.5 x 449 x 43.85







    • Processor / System Bus




      2 x Socket SP5 (LGA 6096)

      AMD EPYC™ 9004 Series

      Max TDP : 400W




    • Generation




      E12




    • Memory




      Total Slots :

      24 (12-channel per CPU, 1 DIMM per CPU)

      Capacity :

      Maximum up to 3072GB per socket

      Memory Type :

      DDR5 4800/4400 RDIMM/ 3DS RDIMM

      Memory Size :

      128GB, 64GB, 32GB RDIMM

      128GB, 64GB, 32GB 3DS RDIMM

      * Refer to www.asus.com/support for more information




    • Expansion Slots




      Up to 3 x PCIe Gen5 slots + 1 x internal RAID slot

      1 x PCIe Gen5 x16 (FHFL)

      1 x PCIe Gen5 x16 or OCP3.0 (FHFL)

      1 x PCIe Gen5 x16 (LP)

      1 x PCIe Gen4 x8 (LP, internal)

      *Installing GPU cards will occupied expansion slots.

      *GPU SKU do not support OCP3.0.




    • Storage




      SATA Controller :

      8 x SATA 6Gb/s ports

      2 x M.2 connectors (SATA 6Gb/s & PCI-E Gen4 x4 link)

      SAS Controller :

      Braodcom HBA CARD 9500-16i (Optional)

      Broadcom MegaRAID 9540-8i (Optional)

      Broadcom MegaRAID 9560-16i (Optional)




    • Drive Bays




      12 x 2.5" Hot-Swap drive bays

      Support up to 12 x NVMe/SATA/SAS*



      *RAID card is required to support SAS hard drives




    • System Fan




      8




    • Networking




      Option 1: 1 x Quad Port Intel I350-AM4 1G LAN Controller + 1 x Mgmt LAN

      Option 2: 1 x Dual Port Intel X710-AT2 10G LAN Controller + 1 x Mgmt LAN

      Option 3: None x + 1 x Mgmt LAN




    • Graphic




      Aspeed AST2600 64MB




    • Multi-GPU Support




      Please find the latest GPU support from https://servers.asus.com/support/gpu




    • Rear I/O Ports




      2 x USB 3.2 Gen1 ports

      1 x VGA port

      1 x RJ-45 Mgmt LAN port

      2 x 10G or 4 x 1G RJ-45 GbE LAN port (Optional)

      1 x OCP3.0 port (Optional)

      *GPU SKU do not support OCP3.0.




    • Switch/LED




      Front Switch/LED:

      1 x Power Switch (w/ LED)

      1 x Reset Switch

      1 x Location Switch (w/ LED)

      1 x HDD Access LED

      1 x Message LED

      LAN 1-4 LED (on NIC module)

      Rear Switch/LED:

      1 x Port 80 LED (Q-Code)

      1 x Power Switch w/ LED

      1 x Location Switch w/LED

      1 x Message LED




    • OS Support




      Please find the latest OS support from https://servers.asus.com/support/os




    • Management Solution




      On-Board ASMB11-iKVM for KVM-over-IP

      ASUS Control Center Enterprise (Optional)




    • Regulatory Compliance




      BSMI, CE, CB, C-Tick, FCC(Class A)




    • Dimensions




      842.5mm x 449mm x 43.85mm (33.17" x 17.68" x 1.73")




    • Form Factor




      1U




    • Weight




      Net Weight : 14.94KG

      Gross Weight : 19.94KG




    • Power Supply




      1+1 Redundant 2000W/1600W 80 PLUS Platinum Power Supply

      1+1 Redundant 2600W/1600W 80 PLUS Titanium Power Supply

      Rating:

      100-127/220-240Vac,12A/9.5A(x2),50/60Hz

      100-127/240Vac,13.8A/16A(x2), 50/60Hz

      220-240Vac, 10A(x2), 50/60Hz




    • Environment




      Operation temperature: 10? ~ 35?

      Non operation temperature: -40? ~ 60?

      Non operation humidity: 20% ~ 90% (Non condensing)




    • Note




      *SAS support only from SAS HBA/RAID Card




    • CPU Heatsink/ Cooler




      2




    • Fan




      1 (For supporting GPU SKU, it will have external fan)


















    • Products certified by the Federal Communications Commission and Industry Canada will be distributed in the United States and Canada. Please visit the ASUS USA and ASUS Canada websites for information about locally available products.

    • All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

    • Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details.

    • PCB color and bundled software versions are subject to change without notice.

    • Brand and product names mentioned are trademarks of their respective companies.

    • The terms HDMI and HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.




    • The information contained is general testing result for reference. Please consult local sales representative for more information on specific supported CPU list on each system.

    • * Optional means “built for order”.








    EAN: 4711387074008

    Doplňkové parametry

    Kategorie: Servery
    Záruka: 3 roky
    Hmotnost: 25 kg
    EAN: 4711387074008
    Kód výrobce: 90SF02D1-M001A0
